DIN bolts are not the appropriate solution for every application. That is why we also manufacture special bolts based on customer-specific specifications. We also manufacture highly complex variants reliably and in outstanding quality, irrespective of whether you need only a small quantity or a large series run.

Range of services for custom bolts (extract)

Material
  • Undercut steel
  • Stainless steel A2 quality
  • Stainless steel A4 quality
  • Other steels that are particularly corrosion-resistant, salt water-resistant or heat-resistant, as well as high-tensile steels
Surface
  • Coating
    • electroplated galvanised
    • mechanically galvanised
    • Special surface
  • Treatment
    • free of grease
    • defined oil film
  • Finishing
    • Grinding
    • Tempering
    • Nitrocarburizing
Machining range
  • round Ø 4 mm up to Ø 65 mm
  • Length from 5 mm up to 350 mm
Options
  • Spanner surface
  • Hole
  • Thread types:
    • metric or inch thread
    • regular, fine-pitch and left hand thread
  • Custom marking
  • Bolts according to DIN / EN / ISO
